Glass Options

Vinylbilt is pleased to be offering LoE-180 and LoE-366 glass, designed specifically for the Canadian climate. Our LoE Glass, provides the Clearest, Highest Performance Glass on the market.

Super Spacer

Super Spacer© Premium Enhanced features:

• Low conductivity
• Edge-seal durability
• Highly breathable flexible foam matrix
• High desiccant content for moisture absorption
• High-quality sillicone
• Superior argon gas retention

Triple-pane glass
Double-pane glass
LOE 180 LOE 366

LOE 180 Cardinal CG - Simply Clean

BENEFITS

• Triple Glazed Performance in a Double Glazed format
• Superior LoE Performance versus other LoE’s
• Energy Star Zone at a minimum C or greater
• Leading blockage of UV Radiation that cause fading & damage
• High Solar Heat Gain
• Comes standard with our Simply Clean super smooth finish
• No Haze

The New LoE 180 glass acts like an invisible layer of insulation that helps homes stay warm and cozy; by blocking heat loss to the cold weather outside and welcoming the sun’s heat inside. This is important because windows contribute up to 25% of the annual heating cost of a home.

Our energy optimization results begin with a selection of LoE glass coating used in combination with our warm edge Super Spacer. We then offer you a choice of double or triple glass panes with argon gas between the panes of glass. In the winter, they help bring in more heat energy during the day, while reducing heat loss at night. In the summer, the same technology prevents hot, humid air from entering your home. The results: reduced air conditioning costs when it’s warm, and lowered heating bills when it’s cold.

DESIGNED FOR OUR CANADIAN CLIMATE

The New LoE 180 glass provides Year Round Comfort and improves the insulating value of your window up to 40%.With high solar heat gain, ER and R values, increased zone coverage and great light transmission and clarity; the New LoE-180, is the Clearest, Highest Performance Glass on the market.



New LOE-180 Performance improvement
Window
Model
Glaze
Window
Solar Heat Gain (SHGC)
Energy Star Zones
Window
Model
Casement
LoE-180 Argon
LoE-180 Argon
Glaze
Window
3
2
0.37
0.41
Solar Heat Gain (SHGC)
Energy Star Zones
28
29
AB
ABC

*From NRCan website

Center of glass comparisons
Product
Energy Rating (ER)
Insulating U Value
Solar Heat Gain (SHGC)
Product
Energy Rating (ER)
Cardinal LoE-180 Guardian 75/68 PPG SG400 AGC Camf.EPS Pilkington Energy Adv.
47.33 45.22 45.79 45.82 45.66
Insulating U Value
Solar Heat Gain (SHGC)
0.259 0.275 0.278 0.290 0.296
0.685 0.683 0.699 0.726 0.735

*Source: Cardinal Glass Industries

LOE 366 Cardinal CG

The ultimate performance glass! LoE366 glass delivers the ideal balance of solar control and high visibility. LoE366 glass provides the highest level of year-round comfort and energy savings, making it the perfect glass no matter where you live.

BENEFITS

• An unprecedented third layer of silver
• Blocks 95% of the damaging UV rays
• Blocks 64% of unwanted heat
• Retains 98% of the room side heating or cooling
• Highest R value for better insulating performance
• No Haze

Advantage LOE

• Other low-e products reflect solar infrared heat, lowering the solar heat gain and minimizing the benefits of passive solar heat.
• Allows the beneficial winter heat to easily pass through the glazing
• Free Energy from the sun

HPE glass (L8+)

• Delivers improved performance vs. single LoE glass in a triple pane format
• Combines 4 layers of LoE in a triple pane unit
• Cardinal (366) is placed on the outer pane of glass and Cardinal (180) on the inbound pane
• Two chambers can be filled with Argon or Krypton gas
• Available with internal and external grills
• Available on all Vinylbilt Platinum Series Windows

Sound Reduction (SSP)

When you combine the Super Spacer© spacer bar, optimal air space and SSP® Glass you obtain significant sound reduction.

Security

Outer layer of glass combined with SSP® glass provides 10 times the security

Performance

LoE glass combined with SSP, provides improved U, R and SHGC values
